GI Building Sciences

AirFlo™ Reflecta VPM (Wall)

Vapour Permeable Membrane

5.0

Product Highlights

Need help understanding if this product is right for you? Contact our team today and we’ll be happy to help.

Use our store finder tool to locate a retailer near you. Click the link below.

Australian Owned Icon
Australian
Owned
Local Stock Icon
Local
Stock
Over 200 Stockists Icon

Over 200 Stockists

Commercial & Residential GIBS

Commercial & Residential

Description

AirFlo™ Reflecta VPM is designed to be used in wall construction.AirFlo™ Reflecta VPM has been engineered to meet the demands of the Australian climate. AirFlo™ Reflectca VPM is specifically designed with one side of heavy duty foil to overcome thermal bridging in a wall, and provide additional thermal performance. Delivering a shield of protection to help against external weather penetration whilst also alleviating condensation build-up.An average household can generate up to 12 litres of internal condensation on a daily basis. Condensation within the frame can result in accelerated frame deterioration, mould infestations, sick building syndrome and costly repairs.Using the right Vapour Permeable weather barrier helps manage condensation and saves you future headaches.

Installation

Download our installation guide:

Technical

Download our technical sheet information:

Warranty

Warranty Info GI in our name reflects our commitment to creating and developing Green Insulation (GI) products for the global commercial and home insulation markets. GI Building Sciences® Warranty/Guarantee statement. The warranty period is for 15 years from the date of manufacture which is printed on our rolls of insulation The GI Building Sciences Insulation warranty covers oxidisation and corrosion for 15 years from manufacture (subject to storage, transport and installation conditions).

GI Building Sciences® also warranty against faulty manufacture or failure of their products for 15 years. To claim against warranty, please contact GI Building Sciences® direct on (07) 3200 6522 GI Building Sciences® will bear all reasonable costs to the user for any claims on warranty, anywhere within Australia.

Warranties and guarantees from GI Building Sciences are in addition to other rights and remedies of the customer under law Warranties and guarantees are conditional upon our products being used, stored, applied and installed as per the manufacturers specifications on each product as described by the Company. “Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.

You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.” “GI Building Sciences® genuinely stand up for quality and responsible Australian manufacturing.

Our new reflective foil manufacturing plant at Meadowbrook in Queensland produces the highest quality aluminium reflective bubble foil insulation in Australia. I give you this guarantee of my personal attention to ANY claim for ANY reason”.

Product Testing Analysis
Results
Duty ClassificationAS/NZS 4200.1 Table - Light Wall
Burst StrengthAS 2001.219 - 550N
Edge Tear ResistanceTAPPI T470 - 569, 484N
Emittance ValueAS/NZS 4201.5 - 0.03, 0.47
Emittance CategoryAS/NZS 4200.1 Table 3 - RN
Vapour PermeabilityASTM E96 - 1.1612ug/N.s
Vapour ControlAS/NZS 4200.1 Table 4 - Class 4, Vapour Permeable
Water ControlAS/NZS 4201.4 - Water Barrier
Air ControlISO 5636-5 - >0.1MNS/m3, Air Barrier
Resistance to Dry DelaminationAS/NZS 4201.1 - Pass
Resistance to Wet DelaminationAS/NZS 4201.2 - Pass
ShrinkageAS/NZS 4201.3 - <0.5%
Electrical ConductivityAS/NZS 3100 - Non-Conductive
Surface Water AbsorbencyAS/NZS 4201.6 - <100g/m2, Low
FlammabilityAS/NZS 1530.2 - Low (<5)
Nominal ThicknessNot Available - <1mm
UV ExposureNot Available - 180 Days
Folding EnduranceAN/NZS 1301.423 - Pass

Specifications

Product Details
Product CodeAFR3530W
Roll QTY1
Roll Width (m)1.35
Roll Length (m)30
Roll Area (m2)40.5
Roll Diameter (m)0.12
Roll Weight (kg)7.17
Vapour ControlClass 4, Vapour Permeable
Vapour Control StandardAS/NZS 4200.1 Table 4
Application TypeCommercial, Residential
LocationRoof
VPM TypeVapour Permeable Membrane (VPM)
