GI Building Sciences
Reflecta Under-Slab™
5.0
- Product Location: Slab
Product Highlights
- Easy to install and highly thermally efficient solution to insulating under suspended floors
- The insulation is thermally bonded with up to 90% recycled content, making it an environmentally friendly product
- This robust underfloor insulation system is designed specifically for the Australian Climate
- Suitable for both suspended and raised timber floors between joists, as well as in solid concrete floors and tiled surfaces
Need help understanding if this product is right for you? Contact our team today and we’ll be happy to help.
- Our team will get back to you within the same day.
Use our store finder tool to locate a retailer near you. Click the link below.

Owned

Stock

Over 200 Stockists

Commercial & Residential
Description
Warranty
Products are to be stored flat on a clean, level surface and kept under cover. Returns of product displaying effects of deformation due to incorrect storage practices will not be accepted.
The product information included in this publication is provided in good faith in order to ensure the optimum performance of this product. However, no warranty is given or implied with respect to this information or the product itself regarding the product’s suitability for any particular purpose, as factors outside our knowledge and control may affect its use.
The usage of this and other building membranes will affect moisture migration in the building element. The purchaser is responsible for independently determining the suitability of the product for the intended purpose. GI Building Sciences Pty Ltd reserves the right to amend product specifications without prior notice. Information provided is considered to be true and correct at the time of publication.
Product Testing Analysis
Results
Surface Corrosion | AS/NZS 4859.1 Appendix I - Pass (Reflective Side Only) |
Thickness | AS/NZS 4347.9 - Comply |
Impact Resistance | AS/NZS 4347.6 - High Impact Resistance |
Vapour Permeance | ASTM E96 - Comply |
Falling Aggregate | CSIRO Method - Comply |
Specifications
Product Details
Product Code | CTW1650 |
R Values
Roll Value Roof Inward (m2K/W) | 225:0.45 300:0.45 |
Roll Value Roof Outward (m2K/W) | 225:1.59 300:0.45 |
Roll Information
Roll QTY | 1 |
Roll Width (m) | 1.5 |
Roll Length (m) | 50 |
Roll Area (m2) | 75 |
Key Information
Application Type | Commercial, Residential |
Location | Slab |
VPM Type | Reflective Damp-Proofing Membrane |
