Reflecta-Shield V2™
5.0
Available in Over 200 Stockists Nationwide
+ more!
Reflecta-Shield V2™
5.0
Product Highlights
- Amongst the highest performing R-value Reflective Products on the market
- Able to be cut to length for major projects
- Made with up to 10% recycled materials
- 15 Year warranty
- The Entry Level all-rounder suited to Commercial, Domestic or Shed Construction Projects
Need help understanding if this product is right for you? Contact our team today and we’ll be happy to help.
- Our team will get back to you within the same day.
Use our store finder tool to locate a retailer near you. Click the link below.
Owned
Stock
Over 200 Stockists
Commercial & Residential
Description
Installation
Roof (Commercial) Installation Guide:
Roof (Residential) Installation Guide:
Wall Installation Guide:
Warranty
Warranty Info GI in our name reflects our commitment to creating and developing Green Insulation (GI) products for the global commercial and home insulation markets. GI Building Sciences® Warranty/Guarantee statement. The warranty period is for 15 years from the date of manufacture which is printed on our rolls of insulation The GI Building Sciences Insulation warranty covers oxidisation and corrosion for 15 years from manufacture (subject to storage, transport and installation conditions).
GI Building Sciences® also warranty against faulty manufacture or failure of their products for 15 years. To claim against warranty, please contact GI Building Sciences® direct on (07) 3200 6522 GI Building Sciences® will bear all reasonable costs to the user for any claims on warranty, anywhere within Australia.
Warranties and guarantees from GI Building Sciences are in addition to other rights and remedies of the customer under law Warranties and guarantees are conditional upon our products being used, stored, applied and installed as per the manufacturers specifications on each product as described by the Company. “Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.” “GI Building Sciences® genuinely stand up for quality and responsible Australian manufacturing.
Our new reflective foil manufacturing plant at Meadowbrook in Queensland produces the highest quality aluminium reflective bubble foil insulation in Australia. I give you this guarantee of my personal attention to ANY claim for ANY reason”.
Product Testing Analysis
Results
Thermal Performance | ASTM C518 |
Material Thermal Resistance | 0.10 (M2K/W) |
Flammability Index | AS 1530.2 |
Ignitability Index | AS/NZS 1530.3 |
Spread of Flame Index | AS/NZS 1530.3 |
Heat Evolved Index | AS/NZS 1530.3 |
Smoke Developed Index | AS/NZS 1530.3 |
Textile Testing | Extra Heavy Duty |
Resistance to Dry Delamination | AS/NZS 4201.1 |
Resistance to Wet Delamination | AS/NZS 4201.2 |
Shrinkage | AS/NZS 4201.3 |
Water Penetration | AS/NZS 4201.4 |
Water Absorbency | AS/NZS 4201.6 |
Water Vapour Transmission | ASTM E96 |
Edge Tearing Resistance | TAPPI T470 om-89 |
Surface Corrosion | AS/NZS 4859.1 Appendix I |
Acoustic | ISO 354 AS ISO 11654 AS 1191 AS/NZS ISO 717.1 |
Impact Resistance | AS 2870 |
Specifications
Product Details
Product Code | RSV2 |
R Values
R Value Wall Inward (m2k/w) | 1.8 |
R Value Wall Outward (m2k/w) | 1.8 |
R Value Roof Inward (m2k/w) | 3.1 |
R Value Roof Outward (m2k/w) | 1.2 |
Material R Value at 23deg | 0.1 |
Roll Information
Roll QTY | 1 |
Roll Width (m) | 1.35 |
Roll Length (m) | 22.25 |
Roll Area (m2) | 30 |
Roll Diameter (m) | 0.28 |
Roll Weight (kg) | 12 |
Roll Size | 22.25M X 1.35M (30M2) |
Product Thickness | 4.0MM (±0.5MM) |
Key Information
Silver Side Emittance | 0.03 |
Antiglare Side Emittance | 0.05 |
Vapour Control Standard | ASTM E96 |
Application Type | Commercial, Residential |
Location | Roof, Wall |
Product Type | Thermal & Sound Insulation |
