GI Building Sciences
Reflecta-GDI™
5.0
GI Building Sciences
Reflecta-GDI™
5.0
- Product Location: Garage Door, Garage Door Insulation
Product Highlights
- No tradesman required
- Excellent acoustic properties
- Eco friendly and fibre-free
- Excellent fire properties
- Unique patented protective durable polymer coating that guarantees against oxidization and corrosion
- Heat laminated, air bubble core providing and exceptional barrier against conductive heat, humidity, water and vapour penetration
Need help understanding if this product is right for you? Contact our team today and we’ll be happy to help.
- Our team will get back to you within the same day.
Use our store finder tool to locate a retailer near you. Click the link below.
Owned
Stock
Over 200 Stockists
Commercial & Residential
Description
Warranty
Warranty Cover
GIBS warrants the products listed below against manufacturing defects for 15 years from the date of installation. The products are also warranted on delivery to meet the applicable GIBS product specifications and the standards stated in the relevant GIBS technical literature.
Conditions
This warranty applies only where the product remains unaltered, has been correctly stored and handled, and has been installed by a suitably qualified tradesperson in accordance with GIBS installation instructions and technical information current at the date of installation.
Claims
A warranty claim must be submitted to the supplier from whom the product was purchased, together with proof of purchase and sufficient details and evidence of the fault and its extent. The supplier must forward the claim to GIBS. All expenses incurred in making a claim under this warranty are borne by the claimant.
Remedy and Liability
Where GIBS accepts a valid warranty claim, GIBS may, at its option, repair, rectify or replace the affected product. GIBS’ liability is limited to the replacement cost of the defective material, reduced proportionately according to the part of the 15-year warranty period that has expired.
The warranty applies only to the original building project and is limited to the GIBS product found to be defective.
To the extent permitted by law, GIBS gives no other express or implied warranty in relation to the product, including its fitness for a particular residential or commercial application other than its published recommended use. Subject to rights that cannot lawfully be excluded, GIBS will not be liable in contract, tort, negligence, strict liability, breach of statutory duty or otherwise beyond the obligations stated in this warranty.
Exclusions
- damage to other products used with a GIBS product, or damage resulting from the installation of those products;
- claims relating to another manufacturer’s product;
- damage arising from recommendations made by a GIBS representative concerning other products, materials or combinations of products;
- damage caused by the installation or assembly of the GIBS product;
- incorrect installation or incompatibility with other materials or products;
- use of the product for applications or purposes outside its intended or published recommended use, including uses outside the building and construction industry;
- damage caused by aggressive chemicals, incompatible metals, immersion in water, chemically treated or green timber, storm, tempest or other events beyond GIBS’ control; or
- normal fair wear and tear.
The buyer is responsible for determining the suitability and compatibility of other products, materials, or the environment of the installation site used with GIBS products and should obtain independent advice where appropriate.
Transfer and Change of Use
This warranty applies only to the original project and application and is not transferable. A change in building ownership or in the purpose or use of the building will cancel this warranty unless GIBS is notified beforehand and confirms that the warranty remains valid for the proposed use.
Australian Consumer Law
This warranty is provided in addition to other rights and remedies available under law.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Product Testing Analysis
Results
| Thermal Performance | ASTM C518 |
| Material Thermal Resistance | 0.20 (M2K/W) |
| Flammability Index | AS/NZS 1530.3 |
| Ignitability Index | AS/NZS 1530.3 |
| Spread of Flame Index | AS/NZS 1530.3 |
| Heat Evolved Index | AS/NZS 1530.3 |
| Smoke Developed Index | AS/NZS 1530.3 |
| Textile Testing | Extra Heavy Duty |
| Resistance to Dry Delamination | AS/NZS 4201.1 |
| Resistance to Wet Delamination | AS/NZS 4201.2 |
| Shrinkage | AS/NZS 4201.3 |
| Resistance to Water Penetraton | AS/NZS 4201.4 |
| Water Absorbency | AS/NZS 4201.6 |
| Water Vapour Transmission | ASTM E96 |
| Edge Tearing Resistance | TAPPI T470 om-89 |
| Surface Corrosion | AS/NZS 4859.1 App 1 |
| Acoustic | ISO 354 |
Specifications
Product Details
| Code | RGD123 |
R Values
| R Value Garage Door Inward (m2K/W) | 1.9 |
| R Value Garage Door Outward (m2K/W) | 1.9 |
| Material R Value at 23Deg | 0.12 |
Roll Information
| Roll Qty | 1 |
| Roll Width (m) | 0.5 |
| Roll Length (m) | 24 |
| Roll Area (m2) | 12 |
| Roll Weight (kg) | 5.5 |
Key Information
| Silver Side Emittance | 0.03 |
| Antiglare Side Emittance | 0.05 |
| Application Type | Residential |
| Location | Garage Door |
| Product Type | Garage Door Insulation |
| Structure Suitability | Garage Door |
